DVGW-PP screw connection
Product information "DVGW-PP screw connection"
one side screw connection, other side male thread
| Certification: | DVGW |
|---|---|
| Gasket: | NBR for potable water |
| Material: | PP |
| Male thread | d | WP (bar) | Packing unit (piece) | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|
| 1/2" | 16 | 16 | 140 | 4601016013 | ||
| 3/4" | 16 | 16 | 140 | 4601016019 | ||
| 1/2" | 20 | 16 | 80/380 | 4601020013 | ||
| 3/4" | 20 | 16 | 80/380 | 4601020019 | ||
| 1" | 20 | 16 | 80/380 | 4601020025 | ||
| 1/2" | 25 | 16 | 50/240 | 4601025013 | ||
| 3/4" | 25 | 16 | 50/240 | 4601025019 | ||
| 1" | 25 | 16 | 50/220 | 4601025025 | ||
| 3/4" | 32 | 16 | 30/160 | 4601032019 | ||
| 1" | 32 | 16 | 30/160 | 4601032025 | ||
| 1 1/4" | 32 | 16 | 30/150 | 4601032032 | ||
| 1 1/2" | 32 | 16 | 30/140 | 4601032038 | ||
| 1" | 40 | 16 | 20/90 | 4601040025 | ||
| 1 1/4" | 40 | 16 | 20/85 | 4601040032 | ||
| 1 1/2" | 40 | 16 | 20/85 | 4601040038 | ||
| 2" | 40 | 16 | 20/85 | 4601040050 | ||
| 1" | 50 | 16 | 50 | 4601050025 | ||
| 1 1/4" | 50 | 16 | 50 | 4601050032 | ||
| 1 1/2" | 50 | 16 | 50 | 4601050038 | ||
| 2" | 50 | 16 | 50 | 4601050050 | ||
| 1 1/4" | 63 | 16 | 28 | 4601063032 | ||
| 1 1/2" | 63 | 16 | 28 | 4601063038 | ||
| 2" | 63 | 16 | 28 | 4601063050 | ||
| 2 1/2" | 63 | 16 | 25 | 4601063063 | ||
| 2" | 75 | 16 | 18 | 4601075050 | ||
| 2 1/2" | 75 | 16 | 18 | 4601075063 | ||
| 3" | 75 | 16 | 18 | 4601075075 | ||
| 2" | 90 | 16 | 10 | 4601090050 | ||
| 2 1/2" | 90 | 16 | 10 | 4601090063 | ||
| 3" | 90 | 16 | 10 | 4601090075 | ||
| 4" | 90 | 16 | 10 | 4601090100 | ||
| 3" | 110 | 16 | 6 | 4601110075 | ||
| 4" | 110 | 16 | 6 | 4601110100 |
Product data sheet
