Worm thread clamps L 9
Product information "Worm thread clamps L 9"
| Certification: | DIN 3017 |
|---|---|
| Material: | Band/housing: rust-free steel 1.4510, AISI 430 Screw: steel, galvanized |
| Clamping range (mm) | Unit | Band width (mm) | Packing unit (piece) | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|
| 8-16 | piece | 9 | 200 | 1502008016 | ||
| 12-22 | piece | 9 | 200 | 1502012022 | ||
| 16-27 | piece | 9 | 200 | 1502016027 | ||
| 20-32 | piece | 9 | 200 | 1502020032 | ||
| 25-40 | piece | 9 | 100 | 1502025040 | ||
| 32-50 | piece | 9 | 100 | 1502032050 | ||
| 40-60 | piece | 9 | 100 | 1502040060 | ||
| 50-70 | piece | 9 | 100 | 1502050070 | ||
| 60-80 | piece | 9 | 100 | 1502060080 | ||
| 70-90 | piece | 9 | 50 | 1502070090 | ||
| 80-100 | piece | 9 | 50 | 1502080100 |
Product data sheet
