DVGW-PP T-fitting 90°
Product information "DVGW-PP T-fitting 90°"
all sides screw connection
| Certification: | DVGW |
|---|---|
| Gasket: | NBR for potable water |
| Material: | PP |
| d | WP (bar) | Packing unit (piece) | Product Number | Delivery Time | |
|---|---|---|---|---|---|
| 20 | 16 | 30/130 | 4607020000 | ||
| 25 | 16 | 15/80 | 4607025000 | ||
| 32 | 16 | 10/50 | 4607032000 | ||
| 40 | 16 | 6/27 | 4607040000 | ||
| 50 | 16 | 15 | 4607050000 | ||
| 63 | 16 | 7 | 4607063000 | ||
| 75 | 16 | 4 | 4607075000 | ||
| 90 | 16 | 2 | 4607090000 | ||
| 110 | 16 | 2 | 4607110000 |
Product data sheet
