Female coupling System Bauer
Product information "Female coupling System Bauer"
with lever arrangement
| Material: | steel, black |
|---|
| NW | Material | Product Number | Delivery Time | |
|---|---|---|---|---|
| 76 | steel, black | 2600076000 | ||
| 89 | steel, black | 2600089000 | ||
| 108 | steel, black | 2600108000 | ||
| 133 | steel, black | 2600133000 | ||
| 159 | steel, black | 2600159000 | ||
| 194 | steel, black | 2600194000 |
Product data sheet
Skip product gallery
Maßtabelle Kupplungensystem Bauer
Das Kupplungensystem Bauer besteht aus einer M-Kupplung (Kugel) und einer V-Kupplung (Becher). Die M-Kupplung hat zusätzlich zu der Kugel einen beweglichen Ring mit aufgesetztem Hebelwerk. Das Hebelwerk greift hinter den Becher der V-Kupplung, um dieses mit der M-Kupplung fest zu verbinden. Das System Bauer ist so konzipiert, dass sich M- und V-Kupplung um bis zu 20° geneigt zusammenkuppeln lassen. Um die exakte Größe der Kupplungen zu bestimmen, wird bei der M-Kupplung der Außendurchmesser und bei der V-Kupplung der Innendurchmesser gemessen.
NW
A (mm)
B (mm)
50 / 2"
70
71
76 / 2 1/2"
98
99
89 / 3"
120
121
108 / 4"
145
148
133 / 5"
158
163
159 / 6"
179
182
194 / 8"
229
231
250 / 10"
305
297
