Pipe clamp
Product information "Pipe clamp"
with rubber inlay, 2-part, galvanized type A: slit on one side with quick release, type B: both sides screw
| Material: | steel, galvanized |
|---|
| Clamping range (mm) | Packing unit (piece) | Female thread | addition2 | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|
| 12-14 | 150 | M8 | type A | 3791012014 | ||
| 15-19 | 150 | M8 | type A | 3791015019 | ||
| 20-23 | 100 | M8 | type A | 3791020023 | ||
| 20-25 | 100 | M8 | type B | 3791020025 | ||
| 24-28 | 100 | M8 | type A | 3791024028 | ||
| 26-30 | 100 | M8 | type B | 3791026030 | ||
| 31-35 | 50 | M8 | type A | 3791031035 | ||
| 40-43 | 50 | M8 | type A | 3791040043 | ||
| 44-49 | 50 | M8 | type A | 3791044049 | ||
| 50-56 | 50 | M8/M10 | type A | 3791050056 | ||
| 57-61 | 50 | M8/M10 | type A | 3791057061 | ||
| 63-67 | 50 | M8/M10 | type A | 3791063067 | ||
| 74-80 | 50 | M8/M10 | type A | 3791074080 | ||
| 83-91 | 50 | M8/M10 | type A | 3791083091 | ||
| 101-106 | 25 | M8/M10 | type A | 3791101106 | ||
| 108-114 | 25 | M8/M10 | type A | 3791108114 | ||
| 122-125 | 25 | M8/M10 | type A | 3791122125 | ||
| 131-135 | 25 | M10 | type A | 3791131135 | ||
| 140-144 | 15 | M10 | type A | 3791140144 | ||
| 159-163 | 15 | M10 | type A | 3791159163 | ||
| 193-200 | 15 | M10 | type A | 3791193200 |
Product data sheet
