PVC butterfly valve type COBI
Product information "PVC butterfly valve type COBI"
with grid lever
| Gasket: | EPDM |
|---|---|
| Gate: | PVC |
| Material: | PP/GFK |
| Spindle: | stainless steel |
| d | hole circle (mm) | overall length (mm) | DN | Packing unit (piece) | WP (bar) | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|---|---|
| 63 | 120 | 44 | 50 | 10 | 10 | 4583063000 | ||
| 75 | 145 | 32 | 65 | 10 | 10 | 4583075000 | ||
| 90 | 156 | 51 | 80 | 10 | 10 | 4583090000 | ||
| 110 | 183 | 55 | 100 | 8 | 10 | 4583110000 | ||
| 125 | 211 | 64 | 125 | 4 | 10 | 4583125000 | ||
| 140 | 211 | 67 | 125 | 4 | 10 | 4583140000 | ||
| 160 | 239 | 72 | 150 | 4 | 10 | 4583160000 | ||
| 200 | 292 | 90 | 200 | 4 | 10 | 4583200000 | ||
| 225 | 292 | 90 | 200 | 2 | 10 | 4583225000 |
