Tension jaw clamps W2
Product information "Tension jaw clamps W2"
wide-band clamp with open able bridge piece and with rounded clamp band edges
| Material: | Band/housing: rust-free steel 1.4510, AISI 430 Screw: with hexagon, steel 8.8, galvanized |
|---|
| Clamping range (mm) | Unit | Packing unit (piece) | Band width (mm) | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|
| 17-19 | piece | 50 | 18 | 1525017019 | ||
| 19-21 | piece | 50 | 18 | 1525019021 | ||
| 21-23 | piece | 50 | 18 | 1525021023 | ||
| 23-25 | piece | 50 | 18 | 1525023025 | ||
| 25-27 | piece | 50 | 18 | 1525025027 | ||
| 27-29 | piece | 50 | 18 | 1525027029 | ||
| 29-31 | piece | 50 | 20 | 1525029031 | ||
| 31-34 | piece | 50 | 20 | 1525031034 | ||
| 34-37 | piece | 50 | 20 | 1525034037 | ||
| 37-40 | piece | 50 | 20 | 1525037040 | ||
| 40-43 | piece | 50 | 22 | 1525040043 | ||
| 43-47 | piece | 50 | 22 | 1525043047 | ||
| 47-51 | piece | 50 | 22 | 1525047051 | ||
| 51-55 | piece | 25 | 22 | 1525051055 | ||
| 55-59 | piece | 25 | 22 | 1525055059 | ||
| 59-63 | piece | 25 | 22 | 1525059063 | ||
| 63-68 | piece | 25 | 24 | 1525063068 | ||
| 68-73 | piece | 25 | 24 | 1525068073 | ||
| 73-79 | piece | 25 | 24 | 1525073079 | ||
| 79-85 | piece | 25 | 24 | 1525079085 | ||
| 85-91 | piece | 25 | 24 | 1525085091 | ||
| 91-97 | piece | 25 | 24 | 1525091097 | ||
| 97-104 | piece | 25 | 24 | 1525097104 | ||
| 104-112 | piece | 25 | 24 | 1525104112 | ||
| 112-121 | piece | 25 | 24 | 1525112121 | ||
| 121-130 | piece | 25 | 24 | 1525121130 | ||
| 130-140 | piece | 10 | 26 | 1525130140 | ||
| 140-150 | piece | 10 | 26 | 1525140150 | ||
| 150-162 | piece | 10 | 26 | 1525150162 | ||
| 162-174 | piece | 10 | 26 | 1525162174 | ||
| 174-187 | piece | 10 | 26 | 1525174187 | ||
| 187-200 | 10 | 26 | 1525187200 | |||
| 200-213 | piece | 10 | 26 | 1525200213 | ||
| 213-226 | piece | 10 | 26 | 1525213226 |
