COBIDUST SIL 2 - High temperature silicon exhaust ventilation hose
Product information "COBIDUST SIL 2 - High temperature silicon exhaust ventilation hose"
very flexible hose made of two layers of fiberglass, silicone coated, suitable for exhaust industrial ventilation, automotive and plastic industry.
| Colour: | red |
|---|---|
| Structure: | 2 plies of silicon, red with steel wire and double outer glass cord |
| Temperature range: | -80°C up to +250°C |
| Inner-Ø (mm) | Length (m) | Unit | WP (bar) | Vacuum (m WC) | weight (g) | bending radius (mm) | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|---|---|---|
| 38 | 4 | piece | 2,6 | 5,8 | 310 | 18 | 1277038000 | ||
| 51 | 4 | piece | 2,6 | 5,3 | 350 | 24 | 1277051000 | ||
| 63 | 4 | piece | 2,4 | 4,6 | 490 | 31 | 1277063000 | ||
| 70 | 4 | piece | 2,3 | 4,6 | 530 | 35 | 1277070000 | ||
| 83 | 4 | piece | 2,1 | 4 | 640 | 42 | 1277083000 | ||
| 89 | 4 | piece | 2,1 | 4 | 690 | 44 | 1277089000 | ||
| 102 | 4 | piece | 1,9 | 3,5 | 770 | 52 | 1277102000 | ||
| 127 | 4 | piece | 1,4 | 2,1 | 1000 | 64 | 1277127000 | ||
| 152 | 4 | piece | 1,2 | 1,7 | 1200 | 75 | 1277152000 | ||
| 160 | 4 | piece | 1,1 | 1,5 | 1280 | 80 | 1277160000 | ||
| 203 | 4 | piece | 0,7 | 1 | 1650 | 101 | 1277203000 |
Product data sheet
