Worm thread clamps L 9 VA
Product information "Worm thread clamps L 9 VA"
| Certification: | DIN 3017 |
|---|---|
| Material: | Band/housing: stainless steel V2A 1.4301, AISI 304 Screw: stainless steel V2A 1.4301, AISI 304 |
| Clamping range (mm) | Unit | Packing unit (piece) | Band width (mm) | Product Number | Delivery Time | |
|---|---|---|---|---|---|---|
| 8-16 | piece | 200 | 9 | 1512008016 | ||
| 12-22 | piece | 200 | 9 | 1512012022 | ||
| 16-27 | piece | 200 | 9 | 1512016027 | ||
| 20-32 | piece | 200 | 9 | 1512020032 | ||
| 25-40 | piece | 100 | 9 | 1512025040 | ||
| 32-50 | piece | 100 | 9 | 1512032050 | ||
| 40-60 | piece | 100 | 9 | 1512040060 | ||
| 50-70 | piece | 100 | 9 | 1512050070 | ||
| 60-80 | piece | 100 | 9 | 1512060080 | ||
| 80-100 | piece | 50 | 9 | 1512080100 |
Product data sheet
